42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm

Brand Name : HeTai

Model Number : 42BYGH622-28A

Certification : CE ROHS ISO

Place of Origin : China

MOQ : 50

Price : USD

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000 PCS/MONTH

Delivery Time : 28-31 DAYS

Packaging Details : Carton with Inner Foam Box, Pallet

Product Name : Hybrid Stepper Motor

Step Angle : 1.8 °

Lead Wire : 4

Rated Voltage : 4.8V

Current : 1A

Resistance : 4.8 Ω

Inductance : 6mH

Holding Torque : 2.9 Kg.cm

Motor Height : 40 mm

Motor Weight : 0.24 Kgs

Contact Now

Hetai 42BYGH622-28A 42mm nema17 high quality 4.8V 1A wholesale high torque stepper motor hybrid stepper motor

Stepper motor, also known as pulse motor, is based on the most basic principle of electromagnet. It is an electromagnet that can rotate freely. Its action principle is to generate electromagnetic torque by relying on the change of air-gap permeance. Its original model is originated from year to year. Attempts for the purpose of control began around the same time, and it was applied to the electrode conveying mechanism of the hydrogen arc lamp. This is considered the original stepper motor. At the beginning of the twentieth century, stepper motors were widely used in automatic telephone exchanges. As Western capitalist powers competed for colonies, stepper motors were widely used in stand-alone systems such as ships and planes that lacked AC power. The invention of transistors in the late 1950s was gradually applied to stepper motors, making digital control easier. After the 1980s, due to the appearance of cheap microcomputers with multi-functions, the control methods of stepper motors are more flexible and diverse.

Electrical Specification Of Hybrid Stepper Motor

Product Name
Hybrid Stepper Motor
Step Accuracy
± 5%
Dielectric Strength
500V AC 1minute
Ambient Temperature
-20℃~50℃
Insulation resistance
100MΩ Min.500V DC
Step Angle
1.8°
Lead wire
4
Voltage (V)
4.8
Current (A/Phase)
1
Holding Torque (Kg.cm)
2.9 Kg.cm


Mechanical Dimension Of Hybrid Stepper Motor

42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm

Product Range Of Hetai

Our main products are Stepper Motor, Planetary Gearbox& Gearbox Motor, Brushless DC Motor, Servo Motor.

42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm

ChangZhou Hetai Motors is an experienced motor manufacturer. For more than 20 years, Hetai dedicates to provide professional electrical integration design and automation strategies for customers. We have variable manufacturing equipment, such as assembly line, Automatic cylindrical grinder and CNC machining centers as well.

42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm

Market Range of Hetai

42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm

Hetai also sends its products to the USA, Europe, Southeast Asia, and all-around China.

From China to Overseas
Europe:France,Germany,Italy,Spain, Norway etc.
North America: USA,Canada
High quality raw materials
Stator Winding Machine
42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm

CNC Center

Packing&Delivery

42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm

42BYGH622-28A Nema17 High Torque Hybrid Stepper Motor 4.8V 1A 42mm
