Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A

Product Categories
Changzhou Hetai Motor And Electric Appliance Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A

  • 1
  • 2
  • 3

Brand Name : HeTai

Model Number : 57BYGH350C-001-14

Certification : CE ROHS ISO

Place of Origin : China

MOQ : 50

Price : USD

Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 PCS/MONTH

Delivery Time : 25 DAYS

Packaging Details : Carton with Inner Foam Box, Pallet

Product name : Hybrid stepping motor

Step Accuracy : ± 5%

Current : 5.2 A

Step Angle : 1.8 Degree

Insulation Resistance : 100MΩ Min.500VC DC

Rated Voltage : 4.6 V

Number Of Phase : 3

Ambient Temperature : -20℃~+50℃

Holding Torque : 12 Kg.cm

Resistance : 0.8 Ohms/Phase

Inductance : 1.4 MH/Phase

Contact Now

Stepping Motor Phase 3 Nema 23 1.2 Degree 4.6 V Low Noise Wholesale 5.2 A

Nema23 3 Phase Stepper Motors. High torque, Low noise, Step Angle 1.2 Degree.

The stepper motor is a digital input-output device. It is particularly well suited to the type of application where control signals appear as digital pulses rather than analog voltages. One digital pulse to a stepper motor drive or translator causes the motor to increment one precise angle of motion. As the digital pulses increase in frequency, the step movement changes into continuous rotation.

Some industrial and scientific applications of stepper motors include robotics, machine tools, pick and place machines, automated wire cutting and wire bonding machines, and even precise fluid control devices.

Electrical Specification
Number Of Phase 3 Comment
Step Angle 1.2°/Step Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A
Rated Voltage 4.6 V
Current 5.2 A/Phase
Resistance 0.8 Ohms/Phase
Inductance 1.4 MH/Phase
Holding Torque 12 Kg.cm
Insulation Class B

Mechanical Dimension
Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A

Product Application

Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A

Patent certificate
Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A
Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A

Packing&Delivery

Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A
